IS-RSM3A.1 - Tech Solutions

Fitur Unggulan

Keunggulan Produk

Persetujuan & Sertifikasi

csm_LOG_ZUL_ATEX__SALL__AIN__V1_5c46efd86d
ATEX (Europe)
Approved

II 2G Ex ib op is IIC T4 Gb
II 2D Ex ib op is IIIC T135°C Db

csm_LOG_ZUL_IECEx-Zulassung__SALL__AIN__V1_d87ccdfa51
IECEx (International)
approved

Ex ib op is IIC T4 Gb
Ex ib op is IIIC T135°C Db

csm_LOG_ZUL_CSA-Group_Logo__SALL__AIN__V1_647c15a407
NEC500 (North America) approved
approved
Class I, Div 1, Groups A,B,C,D, T4
Class II, Div 1, Groups E,F,G, T135C
Class III
csm_LOG_ZUL_INMETRO-Zulassung-Brasilien__SALL__AIN__V1_42452a948b
INMETRO (Brazil) approved
approved
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db

Aksesoris Produk

IS-RSM3A.1
Carrying systems
Klick Fast Connector IS-RSM3x.x
The Klick Fast Connector, when attached to the IS-RSM3A.1, slides and locks easily into any Klick Fast Dock. Once docked, the IS-RSM3A.1 can be rotated to any of seven ratcheted positions. It is undocked quickly and easily by rotating to its inverted position and sliding it free. Suitable for the devices of the IS-RSM3A.1 series.
Product information Klick Fast Connector IS-RSM3x.x

Termasuk Dalam Paket

Spesifikasi Perangkat​

Dimensions

Size: 104,26 x 64,00 x 32,20 mm

Weight: 287 g

Battery

2200 mAh

replaceable

Types of protection

IP68 dust-/waterproof

MIL-STD 810H

Usable from -20 °C to +55 °C

Amplified loudspeaker

Electret condenser microphone

Omni-Directional

Function key red

Function key red (function key assignable for different 3rd party application; e.g. loneworker protection)

Function keys

Function key left

Function key up

Function key left

Function key circular

Interfaces

charging contacts

8-pin circular ISM interface

16-pin ISM connector
